144,000 Lb. Cap. Mobile Lift System / 460/380V, 50-60HZ, 3-Ph. / Set OF 8.



Features

• Massive 144,000-lb. total lifting capacity handles large commercial trucks, buses, fire apparatus, and multi-axle fleet vehicles.
• Eight synchronized mobile lifting columns provide exceptional flexibility for heavy-duty lifting applications.
• Each column delivers 18,000 lbs. of lifting power for scalable lifting configurations.
• High-voltage 460/380V three-phase power system delivers fast, professional-grade lifting performance.
• SINGLE, PAIR, or TEAM operating modes allow technicians to configure columns for multiple vehicle types and shop workflows.
• Smart electronic controls feature self-diagnostics and self-calibration for precise synchronized lifting.
• Intuitive control panels on every column allow complete operation from any lift position.
• Sealed linear potentiometers provide highly accurate synchronization and level lifting throughout operation.
• Ergonomic pallet-jack-style steering system makes positioning and maneuvering columns fast and easy.
• Crush-Ride™ front wheels with adjustable ride height roll smoothly over uneven floors, expansion joints, and debris.
• Horseshoe wiring configuration uses only three interconnect cables to keep the front or rear work area unobstructed.
• Heavy-duty powder-coated steel construction and enclosed hydraulic components provide long-term durability with minimal maintenance requirements.



Technical

Dimensions (L x W x H)	48.75 x 45 x 146.5	inch
Power supply	460/380 V / 50-60 Hz / 3 Ph	V/Hz/A
Track width	9.5 - 35	inch
Track length	11.5" fork length	inch
Color	Gunmetal Gray
Weight approx.	1,450 lbs per column	lbs
Lifting/lowering time approx.	85	s
Lifting height	71.5	inch
Load carrying capacity	144,000 lbs total	lbs
